DTB-FLE6535 Flexible Anti-metal RFID Tag

DTB-FLE6535 Flexible Anti-metal Tag

Air interface protocol
EPC Global Class1 Gen2 ISO 18000-6C

Operational frequency
US 902-928MHz, EU 865-868MHz

Tag dimensions
65*35*1.25mm / 2.56”*1.38”*0.05”

Mechanical Specification

Material
PET

Operating temperature
-40°C~85°C / -40°F~185°F

Limit temperature
-40°C~120°C / -40°F~248°F

Electrical Specification

Device type
Class 1 Generation 2 passive
UHF RFID transponder

Air interface protoco
EPC Global Class1 Gen2 ISO 18000-6C

Operational frequency
US 902-928MHz, EU 865-868MHz

Chip option
Impinj Monza R6-P

Memory configuration

EPC 96 bits (Can be extended to 128 bits);Unique TID 48 bits; User Memory 32 bits

Application medium
Metal surface

Reading range
Metal surface: US 7.5m, EU 5m;Non-metallic surface: US 3m, EU 1.8m

Warranty
1 year

Environmental Resistance

Expected lifetime
1 years in normal operating conditions

Application Area
