DTB-L95U UHF RFID Label

DTB-L95U UHF RFID Label

Air interface protocol
EPC Global Class1 Gen2 ISO 18000-6C

Operational frequency
Global 860-960MHz

Tag dimensions
104 * 5.5mm

Mechanical Parameters

Base Material
PET

Face material
80g Coated Paper

Liner
Release Paper

Quantity
5000PCS/Roll(Can Be Customized)

Reel Inner Diameter
76.2 mm

Tag dimensions
104 * 5.5 mm

Antenna Dimensions
95 * 3 mm

Electrical Parameters

Air interface protocol
EPC Global Class1 Gen2 ISO 18000-6C

Operational frequency
Global 860-960MHz

IC type
NXP UCODE 9

Memory
EPC 96 bits; TID 96 bits; User Memory: No

IC Life
100,000 Times

Data Retention
10 Years

Application Surface
Non Metal Surface

Read range
About 5 m(US Standard, Handheld 1W)

Other Parameters

Operating temperature
-20°C~80°C

Storage Temperature
20°C~30°C

Storage Humidity
20~90% Relative Humidity

Shelf Life
20°C~30°C,40~60% Relative Humidity, More Than 2 Years

L95U-Self-Adhesive Label Structure
L95U-Read Range
L95U-Sensitivity

Application Area
