ABS7023UA Anti-metal RFID Tag
Air interface protocol
EPC Global Class1 Gen2 ISO 18000-6C
Frequency
(US Standard)902-928 MHz
Tag dimensions
70 * 23.5 * 8.5mm
Mechanical Parameters
Inlay Substrate
PET
Shell material
ABS
Weight
About 12g / piece
Shell Color
Light Blue
Installation Method
Adhesive, Screws, Rivets
Mounting Aperture
4.2mm
Antenna Dimensions
70 * 23.5 * 8.5mm
Electrical Parameters
Air Interface Protocol
EPC Global Class1 Gen2 ISO18000-6C
Frequency
(US Standard) 902-928 MHz
IC Type
NXP UCODE 9xe
Memory
EPC 128 bits;TID 96 bits;User Memory:No
IC Life
100,000 Times
Data Retention
10 Years
Application Surface
Metal Surface
Reading Range
About 5 m (US Standard, Handheld 1W)
Other Parameters
Operating temperature
-20°C~80°C
Ambient temperature
-30°C~120°C
Sealing
IP67
Certification
RoHS
