DTB-C70M UHF RFID Label

DTB-C70M UHF RFID Label

Air interface protocol
EPC Global Class1 Gen2 ISO 18000-6C

Operational frequency
Global 860-960MHz

Tag dimensions
73 * 17mm

Mechanical Parameters

Base Material
PET

Face material
80g Coated Paper

Liner
Glassine

Quantity
2500PCS/Roll(Can Be Customized)

Tag Pitch
40.005 mm

Reel Inner Diameter
76.2 mm

Tag dimensions
73 * 17 mm

Antenna Dimensions
70 * 14 mm

Electrical Parameters

Air interface protocol
EPC Global Class1 Gen2 ISO 18000-6C

Operational frequency
Global 860-960MHz

IC type
Impinj M730

Memory
EPC 128 bits; TID 96 bits; User Memory: No

IC Life
100,000 Times

Data Retention
10 Years

Application Surface
Non Metal Surface

Read range
About 10 m(US Standard, Handheld 1W)

Other Parameters

Operating temperature
-20°C~80°C

Storage Temperature
20°C~30°C

Storage Humidity
20~90% Relative Humidity

Shelf Life
20°C~30°C,40~60% Relative Humidity, More Than 2 Years

C70M-Self-Adhesive Label Structure
C70M-Read Range
C70M-Sensitivity

Application Area
