RAIN/UHF RFID Inlay

Overview

Frequency

    860~960 MHz


Protocol

    EPCglobal Gen2 ISO/IEC 18000-6C


Key Advantages

    ISO 9001: 2008 Approved

    100% Quality Tested

    Flexible MOQ

Descriptions of RAIN/UHF RFID Inlay


Radiofrequency identification (RFID) is a form of wireless communication that uses radio waves to identify and track objects.


RAIN RFID is a passive (battery-free) wireless technology system that connects billions of everyday items to the Internet, enabling businesses and consumers to identify, locate, authenticate and engage each item.


RAIN RFID is used in a wide variety of applications, including inventory management, patient safety, asset tracking and item authentication.


DTB RFID is specialized in developing & manufacturing various kinds of RFID tag to meet RAIN standard. DTB RFID tag enable end-users to reach and sustain high levels of performance in all global RAIN RFID frequency regions.


RFID inlay is the microchip and antenna core of an RFID tag, The RFID inlay production needs to be used to attach chips to the antenna substrate and create inlays for Smart Labels and contactless cards. RFID inlay is an important part of Smart card production. You can make your own craft on one the dry inlay by yourself. In this way, there is more flexibility on the craft.



Specifications of RAIN/UHF RFID Inlay


Materials of RAIN/UHF RFID Inlay

  • Base material: PET

  • Antenna: Aluminum foil


Product Range of RAIN/UHF RFID Inlay

  • Common Type: 9662,9654,9640,9620,H47,B42,R50,R70,L120,etc.

  • Other type will be available base on customization.


Reading Distance of RAIN/UHF RFID Inlay

  • 0.1-8M(depending on antenna and reader)


Data Endurance of RAIN/UHF RFID Inlay

  • More than ten years


Protocol & Chip Options of RAIN/UHF RFID Inlay

SuppliersBrandModel
AlienHiggs®Higgs 3
AlienHiggs®Higgs 4
AlienHiggs®Higgs-EC
AlienHiggs®Higgs 9
ImpinjMonza®Monza 4D/4E/4QT
ImpinjMonza®Monza 5
ImpinjMonza®Monza R6/R6-A/R6-B/R6-P
NXPUCODE®UCODE G2iL
NXPUCODE®UCODE G2iM
NXPUCODE®UCODE 7
NXPUCODE®UCODE 8
NXPUCODE®UCODE DNA



DTB UHF RFID Inlay Overview
