RFID Reader

Custom RFID Reader Manufacturer


The RFID reader is an automatic identification device that can read the data of electronic tags. According to the different readings, tag frequency is divided into low frequency, high frequency, ultra-high frequency reader. RFID reader needs to be equipped with an RFID antenna to read tag information.

DTB RFID Reader Production

  • RFID Desktop Reader
    Key Features: Virtual USB COM interface, micro USB connector Compliant with ISO/IEC14443-4 Type A/B, ISO/IEC15693 international Standard; Available working model of reading/Write or Read UID only;
  • Bluetooth RFID Reader
    Description of RFID Bluetooth ReaderTo fulfill the requirements of the customers for E-wallet, E-commerce applications, this Bluetooth reader supports ISO14443-A or ISO18092 or ISO15693.
Products
Product Inquiry

The Principle of RFID Technology


The basic working principle of RFID technology is not complicated: the Tag into the magnetic field, after receiving the rf signal from the reader, with the energy gained by the induced current send product information stored in the chip (Passive Tag, Passive tags or Passive tags), or take the initiative to send a frequency signal (Active Tag, Active Tag or Active);After reading and decoding the information, the reader sends it to the central information system for relevant data processing.


The RFID label reader: The basic information carrier of the measured object is the electronic RFID card tag, which has two types. The other type is passive, which has no power source of its own and is supplied by an external power. So who's going to power it? It's the card reader in the RFID system. It is a radio frequency transceiver that, once in operation, emits an am signal to activate the electronic tag. In the case of a passive electronic tag, it has to be transmitted power. Of course, the transmission of electrical energy is limited by many external conditions.


Two Types of Readers: Desktop Reader and Bluetooth Reader


Desktop Reader is an ID/ IC reader for both 125KHz and 13.56MHz dual-band. Adopt advanced plug and play, no-drive USB connection technology. By simulating the keyboard output mode, the card number of RFID card can be obtained by swiping card, which is simple and stable. At present, Desktop Reader has been widely used in data entry, information inquiry, Internet bar registration, book lending, conference check-in, and access control.


The Bluetooth RFID reader device is characterized by its read/ write functions, Bluetooth communications, and battery charging management function, etc. To fulfill the requirements of the customers for E-commerce application, this Bluetooth reader supports ISO 14443-A or ISO 18092 or ISO 15693.
